A stainless steel electrode resistant to corrosion and acid. Used for welding tanks and piping in the food & beverage industry (dairy, beer, sugar). Also used to weld metals exposed to acid, gas, steam, and water. Heat resistant up to 400°C. Suitable material grades: X12CrNiTi 18 9, G-X10CrNi 18 8, X10CrNiNb 18 10, X2CrNi 19 11, 347, 321, 304, 304 LN, 302, A296 CF 8 C, A 157 C9, A 320 B 8 C, D, 308, 308L.
Welding Position
| Diameter (mm) | Current (A) |
|---|---|
| 2.00 x 250 | 40-60 |
| 2.50 x 250 | 60-80 |
| 3.20 x 350 | 80-120 |
| 4.00 x 350 | 100-150 |
Covered Electrode
A CrNiMo alloy stainless steel electrode resistant to high current, acid, corrosion, and temperatures up to 400°C. Used to join stainless steel and carbon steel. Widely used in the food and chemical industries (grades 316, 317, 316L, 316Cb, 316Ti).
Covered Electrode
A heat-resistant (1100°C) stainless steel electrode alloyed with CrNi and CrNiAl, used for furnace and boiler fabrication. Highly resistant to corrosion and oxidation. Recommended material grades: X20CrNiSi 25 4, G-X40CrNiSi 27 4, X10CrAl 7, X10CrAl 13, X10CrAl 18, X10CrAl 24, G-X30CrSi 6, G-X40CrSi 17, 327, 310.
Covered Electrode
A Cr-Ni and Cr-Si-Al alloyed stainless steel electrode resistant to heat up to 1200°C, used for cast steel, furnaces, boilers, and pipe. Suited to the ceramics, petrochemical, and cement mill industries. Recommended stainless steel grades: X15CrNiSi 25 20, X12CrNi 25 21, X15CrNi 20 12, G-X 15 CrNi 25 20, G-X40 CrNi25 21, G-X40 CrNi-Si 22 9, X10 CrAl 18, X10 CrAl 24, G-X 40 CrSi 17, 305, 310, 314.
Covered Electrode
A stainless steel electrode resistant to corrosion, humid conditions, and seawater — very well suited for building hydroturbines, compressors, steam power plants, and propeller parts, and for overlay or build-up work. Material grades: X5CrNi 13 4, G-X5CrNi 13 4, X6Cr 13, G-X5CrNi 13 6, 410 NiMo, 410.
